PM864AK01 | ABB AC 800M Processor Unit Kit

Product Overview

The ABB PM864A (3BSE018162R1) is the processor unit only for the AC 800M controller family. Functionally equivalent to PM864, it is used for spare-part replacement or custom configurations where the TP830 baseplate is already installed.

Key Specifications

• Manufacturer: ABB
• Part Number: PM864A (3BSE018162R1)
• Product Type: AC 800M Processor Unit (module only)
• CPU: MPC862 @ 96 MHz
• Memory: 32 MB SDRAM
• Performance: 0.15 ms per 1000 boolean operations
• System: AC 800M / System 800xA
• Baseplate: Not included (requires TP830)
• Power Supply: 24 V DC (via TP830)

Applications

• Spare part replacement
• Processor upgrade on existing TP830
• Repair and maintenance

FAQ

Q: Does PM864A include a baseplate?
A: No, this is the processor module only. Order PM864AK01 for the complete kit with TP830.

Installation Guide

1. Power down the existing baseplate.
2. Remove old processor and install PM864A.
3. Secure screws and reconnect cables.
4. Power up and verify diagnostics.

Selection Tips

• Order PM864A for replacement scenarios where TP830 is retained.
• Verify firmware compatibility before installation.
