ProSoft | MVI69-MNET | CompactLogix Modbus TCP/IP Communication Module

Product Description

The MVI69-MNET Modbus TCP/IP Communication Module is designed by ProSoft Technology to provide CompactLogix controllers with reliable Modbus TCP/IP networking capabilities. This single-slot module enables seamless communication with Modbus-compatible devices, supporting up to 5,000 registers and 100 client commands. With Ladder Logic integration and robust electrical performance, the MVI69-MNET ensures dependable operation in industrial automation systems.

Technical Specifications

• Model Number: MVI69-MNET

• Manufacturer: ProSoft Technology (Allen-Bradley CompactLogix line)

• Product Type: Modbus TCP/IP Communication Module

• Product Line: CompactLogix

• Part Number: MVI69-MNET

• Weight: 3.00 lbs (1.36 kg)

• Slot(s): 1 (single-slot module)

• Data Transfer Type: Ladder Logic

• Registers Supported: Up to 5,000

• Client Commands Supported: Up to 100

• Backplane Current Load: Maximum 800 mA @ 5 VDC

Key Features

• Provides Modbus TCP/IP communication for CompactLogix controllers

• Supports up to 5,000 registers for flexible data mapping

• Handles up to 100 client commands for efficient communication

• Compact single-slot design for easy installation

• Ladder Logic support for seamless integration

Application Scenarios

• Integration of CompactLogix controllers with Modbus TCP/IP devices

• Industrial automation systems requiring Ethernet-based Modbus communication

• SCADA platforms with mixed protocol requirements

• Legacy system upgrades needing Modbus TCP/IP support

FAQ

Q: What controllers are compatible with the MVI69-MNET?  A: It is designed for Rockwell Automation CompactLogix controllers.

Q: How many registers does the module support?  A: Up to 5,000 registers.

Q: What is the maximum number of client commands supported?  A: Up to 100 client commands.

Comparable Models

• MVI69E-MBTCP – Enhanced Modbus TCP/IP module with expanded features.

• MVI56E-MNET – Modbus TCP/IP communication module for ControlLogix systems.
