Schneider Electric DAP 216 Discrete Output Module

Description

The Schneider Electric DAP 216 is a high-performance discrete output module designed for reliable switching in industrial automation environments. This module provides 16 independent relay output channels, making it an ideal solution for controlling field devices such as valves, motors, contactors, and indicator lights. Engineered for seamless integration into Schneider Electric PLC platforms, the DAP 216 ensures robust signal management and operational consistency in demanding control sequences.

Features

• 16 discrete relay output points for high-density field device control.
• Contact rating of 2A per channel at 240V AC or 30V DC.
• 1500V RMS isolation between field wiring and the backplane bus to prevent ground loop interference.
• Compact, DIN-rail mountable design for efficient cabinet space utilization.
• Simplified maintenance due to the absence of internal energy storage components.

Applications

The DAP 216 is widely utilized in industrial automation systems, including:

• Process control and valve actuation.
• Motor start/stop control circuits.
• Status indication and alarm signaling.
• General-purpose discrete switching in PLC-based machine automation.

Technical Specifications

Installation Guidelines

• Ensure the PLC system power is disconnected before installing or removing the module.
• Mount the module securely on a standard DIN rail, ensuring proper alignment with the backplane connector.
• Use shielded cabling for field wiring to minimize electromagnetic interference (EMI).
• Maintain adequate clearance around the module to ensure proper ventilation and cooling within the control cabinet.
• Verify that field device loads do not exceed the 2A per channel current rating to prevent relay damage.

FAQ

Is the DAP 216 compatible with all Schneider PLC systems?

The DAP 216 is designed for integration with specific Schneider Electric platforms such as Advantys or Modicon. Please verify your specific PLC series compatibility before installation.

What is the primary function of the 1500V RMS isolation?

The isolation barrier protects the internal backplane bus and PLC processor from electrical noise, voltage spikes, and ground loops originating from field-side devices.
