Schneider Modicon Quantum BMXDDI1602H X80 Discrete Input Module

Product Overview

The Schneider Electric BMXDDI1602H belongs to the ruggedized Modicon X80 I/O family, serving as a high-density discrete input interface for M340 and M580 automation platforms. This "H" version features specialized hardening to withstand harsh chemical atmospheres and extreme climatic conditions. It processes 16 digital signals from field devices such as sensors, limit switches, and pushbuttons, converting them into actionable data for the CPU. We supply this module as 100% Brand New and Original, ensuring maximum uptime in your most demanding industrial applications.

Technical Specifications

This module utilizes a 20-way removable terminal block and provides high-speed signal processing. The following table highlights its core electrical and physical properties:

Engineering Advantages

The BMXDDI1602H solves specific field integration challenges through its hardened design and flexible configuration:

• Severe Environment Protection: The "H" designation indicates a conformal coating that resists salt spray, corrosive gases (such as $H_{2}S$ and $Cl_{2}$), and high humidity. This eliminates the need for expensive, specialized climate-controlled enclosures in chemical or wastewater plants.

• Extended Thermal Range: While standard modules fail at 60°C, the BMXDDI1602H operates reliably up to 70°C. This prevents thermal shutdowns in outdoor control cabinets or high-heat processing areas.

• Enhanced EMI/RFI Immunity: Advanced internal filtering protects signal integrity against electromagnetic interference from nearby variable frequency drives (VFDs) and high-power switchgear.

• Smart Diagnostics: Front-facing LED indicators provide immediate status for each of the 16 channels. A dedicated "Module" LED flags internal faults, significantly accelerating troubleshooting during commissioning or maintenance cycles.

• Simplified Hot-Swap Maintenance: The module supports hot-swapping within the X80 backplane, allowing technicians to replace faulty units without interrupting the power supply to other critical I/O modules.

FAQs

• What is the difference between the BMXDDI1602 and the BMXDDI1602H?

  The "H" version includes conformal coating and supports an extended temperature range (-25°C to 70°C), whereas the standard version is designed for indoor, controlled environments with a narrower temperature envelope.

• Does this module require a specific terminal block?

  Yes, you must use a 20-way removable terminal block (such as the BMXFTB2010 or BMXFTB2000). Please note that terminal blocks usually ship separately from the module itself.

• Can I use this module with an M580 eX80 Ethernet drop?

  Absolutely. The BMXDDI1602H is fully compatible with both M340 local racks and M580 remote Ethernet I/O drops, providing a versatile solution across your entire site.

• Is this unit original factory stock?

  We guarantee that every BMXDDI1602H we ship is 100% Brand New and original Schneider Electric stock, complete with factory seals and global warranty support.
