Thrust Position Differential Expansion and Rod Position Monitor Emerson Epro A6210
  • Thrust Position Differential Expansion and Rod Position Monitor Emerson Epro A6210
  • Thrust Position Differential Expansion and Rod Position Monitor Emerson Epro A6210
  • Thrust Position Differential Expansion and Rod Position Monitor Emerson Epro A6210
Thrust Position Differential Expansion and Rod Position Monitor Emerson Epro A6210

Emerson

Thrust Position Differential Expansion and Rod Position Monitor Emerson Epro A6210

10 left

  • Manufacturer: Emerson

  • Product No.: A6210

  • Product Type: Thrust Position Differential Expansion and Rod Position Monitor

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 200g

  • Shipping port: Xiamen

  • Warranty: 12 months

Special offer ends!
00 :
00 :
00

Product Overview

The A6210 by Emerson Epro precisely monitors thrust position, differential expansion, and rod displacement in rotating machinery. Its modular design integrates seamlessly with AMS 6500 systems, providing real-time data for predictive maintenance. The device supports high-resolution measurement, ensuring mechanical stability and operational safety.

Technical Specifications

Parameter Details
Model A6210
Manufacturer Emerson Epro
Category Thrust Position Differential & Rod Position Monitor
Series AMS 6500 Classic Protection Card Series
Channels Dual-channel for thrust and rod position monitoring
Input Voltage 24 VDC ±10%
Current Consumption Typical 60 mA, Max 80 mA
Output Signals 4–20 mA analog, digital alarm relays
Response Time <100 ms
Measurement Range Thrust position: ±10 mm; Rod displacement: ±5 mm
Resolution 0.01 mm for rod position, 0.05 mm for thrust
Energy Storage Internal capacitor backup for transient events
Mounting Modular baseplate; DIN rail horizontal/vertical; 19-inch rack with mounting kit
Dimensions (L × W × H) 130 × 85 × 50 mm
Weight 0.55 kg
Material Aluminum housing with corrosion-resistant coating
Operating Temperature -20°C to 70°C
Storage Temperature -40°C to 85°C
Humidity 5–95% RH, non-condensing
Vibration Resistance 5–500 Hz, 2 g RMS
Shock Resistance 30 g, 11 ms half-sine
Certifications CE, UL listed
Communication Interface Compatible with AMS 6500 system bus and standard analog/digital cabling
Installation Components Mounting screws, DIN adapter kit, connection terminals included
Maintenance Field-replaceable modules with easy access to connectors



FAQ

Q1: Is this product brand new and original?
Yes, the A6210 is fully original from Emerson Epro and comes factory-sealed.

Q2: How quickly can you ship this device?
We typically ship within 3 days to 2 weeks depending on order size.

Q3: Which shipping methods are available?
We commonly use DHL, FedEx, and other reliable carriers.

Q4: What if the module has a quality issue?
We support returns within 30 days if there is a manufacturing defect.

Q5: What mounting options does it support?
It supports modular baseplate mounting, DIN rail (horizontal/vertical), or 19-inch rack installation with the kit.

Q6: What is the measurement range of the monitor?
The A6210 measures thrust position ±10 mm and rod displacement ±5 mm.
