TK-FXX102 Honeywell 10-Slot Series A Rack

Product Description

The TK-FXX102 (Part Number: TK-FXX102) is a heavy-duty 10-slot backplane chassis designed for the Honeywell Experion PKS Series A platform. It provides the mechanical structure, regulated power distribution, and high-speed backplane connectivity required to integrate C200 controllers, power supply modules, redundancy modules, and communication interfaces within a single control node.

Optimized for high-density industrial installations, the TK-FXX102 mounts easily into standard 19-inch control cabinets. Its rigid frame construction minimizes board flexing and ensures precise connector alignment, supporting reliable hot-swap module insertion. This chassis is widely used in large-scale process automation environments—such as oil refineries and chemical plants—where maximizing I/O density and system availability is essential.

Technical Specifications

Application Scenarios

• Centralized chassis for high-density C200 controller assemblies

• Expansion of Series A I/O capacity in large Distributed Control Systems (DCS)

• Hosting redundant processor and power supply configurations within a single rack

• Control cabinet standardization in refinery and chemical process units

Frequently Asked Questions

How many power supply modules can the TK-FXX102 support?
The chassis typically supports one or two power supply modules (such as the TK-FPDXX2) to enable redundant power configurations, depending on system design and slot allocation.

Is the TK-FXX102 compatible with Series C modules?
No. The TK-FXX102 is exclusively designed for Series A modules. Series C hardware requires a different chassis and vertical IOTA-based mounting system.
