Triconex Analogue input TA, 16 channel, dual, isolated 9832
  • Triconex Analogue input TA, 16 channel, dual, isolated 9832
  • Triconex Analogue input TA, 16 channel, dual, isolated 9832
  • Triconex Analogue input TA, 16 channel, dual, isolated 9832
Triconex Analogue input TA, 16 channel, dual, isolated 9832

Triconex

Triconex Analogue input TA, 16 channel, dual, isolated 9832

10 left

  • Manufacturer: Triconex

  • Product No.: 9832

  • Product Type: Analogue input TA, 16 channel, dual, isolated

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 170g

  • Shipping port: Xiamen

  • Warranty: 12 months

Special offer ends!
00 :
00 :
00

Product Description

The 9832 analog input module provides high-precision signal acquisition for Tricon safety instrumented systems in industrial environments.
It supports 16-channel dual isolated architecture, ensuring accurate measurement of voltage and current signals.
Additionally, the 9832 integrates seamlessly with Tricon systems, enabling stable and reliable real-time data processing.
Engineers choose the 9832 for its accuracy, isolation design, and long-term operational stability.

Technical Specifications

Parameter Specification Details
Model Number 9832
Manufacturer Triconex (Invensys / Schneider Electric)
Product Type Analog Input Module (TA)
Series Tricon Safety Instrumented System
Input Channels 16 isolated analog input channels
Input Configuration Dual isolated architecture
Signal Types Voltage and current signals
Input Range 0–5 V, 0–10 V, 4–20 mA
Resolution High-resolution A/D conversion
Accuracy High precision industrial-grade measurement
Sampling Rate Fast real-time signal acquisition
Input Impedance High impedance for stable measurement
Isolation Protection Channel-to-channel and channel-to-ground isolation
Diagnostics Capability Continuous channel monitoring
Power Supply Source Tricon backplane powered
Power Consumption Low-power optimized design
Interface Type Backplane connector
Component Design Multi-layer industrial PCB
Dimensions Approx. 300 mm × 200 mm × 50 mm
Weight Approx. 1.5–2.0 kg
Operating Temperature 0°C to 60°C
Storage Temperature -40°C to 85°C
Relative Humidity 5% to 95% non-condensing
LED Indicators Channel status and diagnostics LEDs
Cooling Method Passive chassis airflow
Redundancy Support Compatible with Tricon fault-tolerant systems
EMC Compliance Industrial electromagnetic standards
Installation Method Rack-mounted single-slot design
Maintenance Minimal maintenance required
Application Scope Process control, safety monitoring, industrial automation



FAQ

Q1: What is the main function of the 9832 module?
A1: The 9832 module collects and converts analog signals into digital data for Tricon systems.

Q2: How many channels does the 9832 support?
A2: The 9832 provides 16 dual isolated analog input channels.

Q3: What signal types does the 9832 support?
A3: The 9832 supports voltage and current signals, including 0–10 V and 4–20 mA.

Q4: Does the 9832 include isolation protection?
A4: The 9832 includes dual isolation to reduce interference and improve measurement safety.

Q5: Is the 9832 available in stock?
A5: We supply brand-new original 9832 modules and maintain stock for fast delivery.

Q6: What shipping and return services do you provide?
A6: We ship via DHL and similar carriers within 3 days to 2 weeks and support 30-day returns for quality issues.
Return policy

​We aim to provide reliable products and a smooth purchasing experience. If there is a problem with your order, please contact us and we will assist according to our Refund Policy.
Shipping

We provide international shipping options to meet different delivery requirements. Please review details regarding methods and timelines in our Shipping Policy.
Warranty

We provide a 12-month warranty for all products, subject to normal use and proper installation.
