TSXDST1682 Schneider Electric Compact Output Module
  • TSXDST1682 Schneider Electric Compact Output Module
  • TSXDST1682 Schneider Electric Compact Output Module
  • TSXDST1682 Schneider Electric Compact Output Module
TSXDST1682 Schneider Electric Compact Output Module

Schneider

TSXDST1682 Schneider Electric Compact Output Module

10 left

  • Manufacturer: Schneider

  • Product No.: TSXDST1682

  • Product Type: Compact Output Module

  • Product Origin: France

  • Payment:T/T, Western Union

  • Weight: 510g

  • Shipping port: Xiamen

  • Warranty: 12 months

Special offer ends!
00 :
00 :
00

Product Description

The TSXDST1682 is a 16-channel discrete output module for Schneider Electric Modicon Compact and CNC PLCs. It provides reliable interfacing between controller logic and field actuators, ideal for driving solenoids, relays, and indicators in high-speed, deterministic applications.

Technical Specifications

Item Specification
Output Channels 16 Discrete Outputs
Rated Voltage 24 V DC
Output Current 0.5 A per channel
Logic Type Positive Logic (Sourcing)
Total Module Load Supports simultaneous high-load operation
Operating Temperature 0–60°C (32–140°F)
Humidity ≤ 80% RH, non-condensing
Maximum Altitude 1000 m without derating
Power Dissipation Low heat design
Mounting Compact series rack/base
Weight 0.51 kg

Typical Applications

  • CNC machine tool automation (tool changers, cooling pumps, status indicators)

  • Localized process control in Modicon Compact manufacturing cells

  • High-speed output switching in deterministic control environments

Notes / FAQ

  • Current Limit: 0.5 A per channel; use interposing relays for higher loads

  • Diagnostics: Front LEDs indicate channel status and module power health
