Unity Processor Module Schneider TSXP573634M Modicon Quantum

Product Overview

The Schneider Electric TSXP573634M serves as a high-performance Unity processor for the Modicon Premium automation platform. This module manages complex automation architectures, supporting up to 1024 discrete I/O and 128 analog I/O points. It integrates natively with Unity Pro software and utilizes the "Transparent Ready" concept to provide seamless communication via Ethernet TCP/IP and non-isolated serial links. This processor excels in mid-to-large scale industrial applications requiring fast execution times and extensive diagnostic capabilities.

Condition: 100% Brand New, Original Factory Sealed.

Technical Specifications

The TSXP573634M delivers rapid logic processing and robust memory management.

Engineering Advantages

• High-Speed Logic Execution: The processor executes Boolean instructions in just 0.12 µs. This extreme speed ensures precise control over fast-moving machinery and high-frequency production lines.

• Transparent Ready Connectivity: Integrated Ethernet TCP/IP (10BASE-T/100BASE-TX) eliminates the need for external gateways. It allows direct data exchange between the plant floor and enterprise systems, simplifying the "Transparent Ready" architecture.

• Advanced Diagnostics via LED Array: Ten distinct front-panel LEDs provide real-time feedback on processor health (ERR), I/O status, and network activity (TX/RX/COL). This enables maintenance teams to isolate faults instantly without connecting a laptop.

• Flexible Memory Scaling: Users can expand the 192 kB internal data memory up to 16 MB using PCMCIA cards. This flexibility allows the system to grow with your process without replacing the core processor.

• Marine and Hazardous Area Ready: With certifications like DNV, GL, RINA, and ABS, plus CSA Class I Division 2 compliance, this module operates reliably in marine environments and hazardous industrial zones.

FAQs

• Does this processor require a PCMCIA card to function?

  The TSXP573634M functions without a PCMCIA card for basic applications using its 192 kB of internal RAM. However, for larger program structures or extensive data logging, you must install an additional PCMCIA card to access the full 1792 kB program or 16 MB data capacity.

• How does the "Double Format" affect rack installation?

  This processor occupies two slots on the Modicon Premium rack. Ensure your rack configuration (4, 6, 8, or 12 slots) accounts for this footprint when calculating available space for I/O modules.

• What software do I need to program the TSXP573634M?

  This specific model requires Unity Pro software. It leverages the Unity Pro environment to manage complex function blocks (DFB and EFB) and event-driven tasks.

• Can I use this module in high-altitude environments?

  Yes, the module supports operation at altitudes up to 6561 ft (2000 m). For installations exceeding this altitude, consult technical support for potential thermal derating requirements.
