Westinghouse Ovation 5X00481G04 Controller Model OCR1100

Overview

The Emerson 5X00481G04 is an OCR 1100 Controller CPU Card / Processor Module for the Ovation™ distributed control system. It provides secure, reliable, mission-critical control with seamless automatic failover between redundant controllers, making it ideal for power generation, water treatment, and chemical processing applications.

Technical Specifications

• Manufacturer: Emerson (Westinghouse)
• Model: 5X00481G04
• Type: OCR 1100 Controller CPU Card / Processor Module
• Control Capacity: Up to 32,000 points
• Control Sheets: Executes >1,000 control sheets (average)
• Failover: Bumpless automatic failover between redundant controllers
• Sequence of Events: 1 ms resolution
• Standards: IEC 61131-3, Achilles Level 1 certified

Key Features

• High-speed processor for increased productivity and deterministic control
• One-step data acquisition through I/O database definition
• Compact, fanless design with low power consumption
• Interfaces to Ovation and WDPF I/O (local and remote)
• Virtual I/O capability for third-party OEM systems over Ethernet
• Non-volatile storage for application software, configuration, and tuning constants

FAQ

Q: What industries is this processor used in?
A: It is commonly deployed in power generation, steel production, petroleum, chemical, and water/wastewater industries.

Q: Does it support redundant operation?
A: Yes, it provides bumpless automatic failover between redundant controller pairs.

Q: What is the SOE resolution?
A: The integrated sequence of events capability provides 1 millisecond timestamp resolution.

Installation Guidelines

1. Install the processor module into the primary slot of the Ovation controller rack.
2. For redundancy, install the partner module in the adjacent redundant slot.
3. Connect Ethernet and I/O network cables per the system architecture.
4. Load control sheets and database configuration via Ovation Developer Studio.

Selection Tips

• Choose 5X00481G04 for large-scale Ovation applications requiring up to 32,000 I/O points.
• Verify Ovation software version compatibility before ordering.
• For critical applications, always deploy in redundant pairs for automatic failover.
