Westinghouse Ovation 5X00499G01 Versatile Digital Input Module

Overview

The Emerson 5X00499G01 appears in Ovation™ system documentation with conflicting primary classifications across verified industrial suppliers. It is variously described as a 16-Channel High-Speed Digital Output Module and as a 32-Channel Digital Input Module. The specifications below consolidate all verified data points with conflict annotations.

Technical Specifications — Digital Output Classification

• Manufacturer: Emerson (Westinghouse)
• Model: 5X00499G01
• Type: 16-Channel High-Speed Digital Output Module
• Output Type: Solid-state transistor (sinking/sourcing)
• Load Voltage: 24–48 VDC
• Load Current: Up to 500 mA per channel
• Switching Speed: ≤ 1 ms
• Isolation: Opto-isolation ≥1500 V
• Channels: 16 optically isolated outputs

Technical Specifications — Digital Input Classification

• Type: 32-Channel Digital Input Module
• Input Voltage: 24 VDC
• Weight: 330 g

FAQ

Q: Is this a digital output or digital input module?
A: Verified suppliers conflict. Cxabb.com describes 16-channel high-speed DO; Aeliyamarine.com describes 32-channel DI. Verify your exact part number and system BOM before ordering.

Q: What is the switching speed for digital outputs?
A: Per the DO classification, ≤1 ms—ideal for turbine trip verification and fast interlocks.

Installation Guidelines

1. Verify the exact function of 5X00499G01 in your system architecture before installation.
2. If used as DO, connect field power (24–48 VDC) and load wiring per channel.
3. If used as DI, connect 24 VDC contact closure wiring to input terminals.

Selection Tips

• Do not order blindly. Confirm whether your system requires 5X00499G01 as a 16-channel DO or as a 32-channel DI.
• For high-speed output applications (turbine trips, SOE), verify switching speed ≤1 ms.
