Woodward 8290-195 Flo‐Tech Speed Control

Product Overview

The Woodward 8290-195 is a Flo-Tech Speed Control designed for precise mechanical-hydraulic governor performance in engine applications. It delivers accurate engine speed regulation through a 24VDC-powered control system that interfaces with fuel metering valves and actuators. The Flo-Tech series is particularly suited for engines requiring flow-based fuel control with pre-programmed flow curves for optimal combustion efficiency.

Key Technical Specifications

• Product Type: Flo-Tech Speed Control
• Series: Woodward Flo-Tech Speed Controls / 8290 Series
• Power Supply: 24 VDC
• Control Output: 0–20 mA analog signal
• Connector: 23-pin
• Actuator Interface: Flo-tech fuel metering valve
• Flow Curve: Pre-programmed Flo-tech flow curve
• Control Type: Mechanical-hydraulic governor performance with electronic control
• Application: Engine speed regulation with flow-based fuel control
• Dimensions: 12" W × 12" H × 12" D (approx.)
• Status: Discontinued by Woodward
• Recommended Replacement: 8245-020 (75mm F-series based ITB)
• Origin: USA

Related Flo-Tech Speed Control Models

• 8235-169 — Flo-Tech Speed Control
• 8235-170 — Flo-Tech Speed Control
• 8235-171 — Flo-Tech Speed Control
• 8235-172 — Flo-Tech Speed Control
• 8235-177 — Flo-Tech Speed Control
• 8235-178 — Flo-Tech Speed Control
• 8235-181 — Flo-Tech Speed Control
• 8235-183 — Flo-Tech Speed Control
• 8290-195 — Flo-Tech Speed Control (24VDC)
• 8290-196 — Flo-Tech Speed Control

Key Features

• Flow-Based Fuel Control: Pre-programmed flow curves optimize fuel delivery for combustion efficiency
• Mechanical-Hydraulic Performance: Combines proven governor mechanics with electronic precision
• 0–20 mA Control Signal: Standard analog output for actuator positioning
• 23-Pin Connector: Robust industrial connector for reliable signal transmission
• Engine Speed Regulation: Maintains constant speed under varying load conditions

Replacement Information

• Original Model: 8290-195 Flo-Tech Speed Control
• Replacement Model: 8245-020 (75mm F-series based ITB)
• Replacement Features:
  • Old Flo-tech flow curve pre-programmed
  • 23-pin connector compatible
  • 0–20 mA signal output
  • Flo-tech to F-series cable harness included
• Upgrade Path: Contact Woodward or authorized distributor for migration support

Applications

• Diesel engine speed control with flow-based fuel metering
• Gas engine governor applications
• Industrial engine management systems
• Generator set frequency control
• Marine propulsion engine speed regulation

Installation Guide (Original 8290-195)

1. Mount speed controller in engine control panel
2. Connect 24 VDC power supply
3. Wire 23-pin connector to Flo-tech fuel metering valve
4. Connect 0–20 mA control signal to actuator
5. Configure flow curve parameters via controller interface
6. Verify engine speed regulation under load

Installation Guide (Replacement 8245-020)

1. Remove discontinued 8290-195 from panel
2. Install 8245-020 F-series ITB in same mounting location
3. Connect using included Flo-tech to F-series cable harness
4. Verify pre-programmed flow curve matches engine requirements
5. Calibrate 0–20 mA output signal
6. Test engine speed regulation and confirm performance

FAQ

Q: Is the 8290-195 still available?
A: No. Woodward has discontinued this model. Limited stock may be available from surplus suppliers, but the recommended replacement is 8245-020.

Q: What is the recommended replacement?
A: Woodward recommends 8245-020 (75mm F-series based ITB). The old Flo-tech flow curve is pre-programmed, and a cable harness is included for easy migration.

Q: What is Flo-Tech technology?
A: Flo-Tech is Woodward's flow-based fuel control technology that uses pre-programmed flow curves to optimize fuel delivery for engine combustion efficiency.

Q: What is the control output signal?
A: 0–20 mA analog current signal for actuator positioning.

Q: Can I use the 8290-195 with non-Woodward actuators?
A: The 8290-195 is designed for Woodward Flo-tech fuel metering valves. For other actuators, verify compatibility or consider the replacement 8245-020.

Model Selection Tips

• 8290-195 = Discontinued Flo-Tech Speed Control (24VDC)
• Recommended replacement: 8245-020 (75mm F-series based ITB with pre-programmed flow curve)
• For new installations, order 8245-020 directly instead of 8290-195
• For existing systems, migration kit includes cable harness for plug-and-play replacement
• Verify engine fuel system type (Flo-tech valve) before ordering replacement
• For alternative speed control technologies, consider 9905-792 (ProAct Digital) or 9907-164 (505E)
