ABB Bailey INPCT01 Plant Loop to Computer Transfer Module

Product Overview

The ABB Bailey INPCT01 is a Plant Loop to Computer Transfer Module for the INFI 90 Distributed Control System. It provides the interface between the Plant Loop communication network and external computer systems, enabling data exchange and supervisory control from host computers. The INPCT01 is specifically designed for Plant Loop-based INFI 90 systems, differing from the INICT series which interfaces with INFI-NET.

Key Technical Specifications

• Product Type: Plant Loop to Computer Transfer Module
• Series: ABB Bailey INFI 90
• Function: Plant Loop to computer data transfer
• Communication: Plant Loop to computer interface
• Mounting: INFI 90 Module Mounting Unit (MMU)
• MPN: 50064U
• Origin: Sweden / USA

Key Features

• Plant Loop Interface: Connects Plant Loop network to host computers
• Data Transfer: Enables real-time data exchange for monitoring and control
• SCADA Integration: Supports supervisory control and data acquisition systems
• Industrial Grade: Reliable operation in demanding industrial environments

Applications

• Plant Loop-based INFI 90 to computer interfacing
• SCADA system integration for Plant Loop networks
• Plant information management connectivity
• Process control data historian interfaces

Installation Guide

1. Install INPCT01 in INFI 90 MMU slot
2. Connect Plant Loop cable to network port
3. Wire computer interface cable (RS-232/RS-485 per configuration)
4. Configure data transfer parameters via Bailey software
5. Test communication link with host computer

FAQ

Q: What is the difference between INPCT01 and INICT03?
A: INPCT01 interfaces with Plant Loop networks; INICT03 interfaces with INFI-NET networks.

Q: Can INPCT01 be used with INFI-NET?
A: No, it is specifically designed for Plant Loop communication. Use INICT series for INFI-NET.

Model Selection Tips

• INPCT01 = Plant Loop to Computer Transfer Module
• Verify your system uses Plant Loop (not INFI-NET) architecture
• For INFI-NET to computer transfer, use INICT03/INICT13/INICT13A
• Confirm computer interface type and protocol requirements
