ABB Bailey IPFAN14 Fan Module

Product Overview

The ABB Bailey IPFAN14 is an enhanced Fan Assembly for the INFI 90 and Symphony DCS control system cabinets. It provides increased airflow capacity compared to the IPFAN12, making it suitable for larger cabinets, higher heat loads, or installations in elevated ambient temperature environments. The IPFAN14 ensures reliable thermal management for mission-critical control systems.

Key Technical Specifications

• Product Type: Fan Assembly (Enhanced)
• Series: ABB Bailey INFI 90 / Symphony
• Function: High-capacity cabinet cooling
• Airflow: Higher than IPFAN12
• Mounting: Cabinet or chassis-mounted
• Origin: Sweden / USA

Key Features

• High Airflow: Increased cooling capacity for demanding installations
• Thermal Management: Maintains optimal temperature in large or high-heat cabinets
• Industrial Grade: Designed for continuous operation in harsh environments
• Easy Maintenance: Modular design for quick replacement

Applications

• Large INFI 90/Symphony cabinet cooling
• High-density module installations
• Elevated ambient temperature environments
• Power supply and MMU thermal management

Installation Guide

1. Mount IPFAN14 in designated cabinet location
2. Connect appropriate power supply
3. Verify enhanced airflow meets cooling requirements
4. Monitor temperature after installation

FAQ

Q: When should I choose IPFAN14 over IPFAN12?
A: Choose IPFAN14 for larger cabinets, higher module density, or elevated ambient temperatures requiring increased airflow.

Model Selection Tips

• IPFAN14 = Enhanced Fan Assembly with higher airflow
• For standard cooling, IPFAN12 may be sufficient
• Verify cabinet dimensions and heat load calculations
• Confirm power supply compatibility
