Backplane Power Supply Module Bachmann BS212

Product Description
The BS212 is a high-reliability backplane power supply for the Bachmann M1 automation system. It converts a 24 VDC input into stable internal voltages for CPUs, I/O modules, and high-speed communication cards, ensuring uninterrupted operation in industrial environments with fluctuating field power.

Built for rugged industrial use, the BS212 features galvanic isolation, over-/under-voltage protection, short-circuit safeguards, and thermal monitoring. Its fan-free Austrian design reliably operates from -30°C to +60°C, providing a slim 25 mm footprint for efficient cabinet integration.

Technical Specifications

• Module Type: Backplane Power Supply & Bus Distribution

• System Series: Bachmann M1

• Input Voltage: 24 VDC (18–32 VDC operating range)

• Output Current: Up to 10 A (dependent on configuration)

• Power Consumption: 15 W

• Protection: Short-circuit, thermal, over-voltage, under-voltage

• Isolation: Galvanic isolation between input and system bus

• Visual Diagnostics: LED indicators for power status and faults

• Dimensions: 130 × 25 × 150 mm

• Weight: 2kg

• Operating Temperature: -30 °C to +60 °C

Applications
Ideal for mid-to-large M1 systems, including wind turbines, maritime automation, and large-scale manufacturing. Supports multiple high-performance modules such as MC212 or DPM200.

Product FAQ
Q: Can the BS212 power external field devices?
A: No, it is designed solely for the M1 backplane. External devices require a separate supply like the CPC210.

Q: How can I monitor the power supply health?
A: Front LEDs show real-time status, and the Bachmann SolutionCenter allows programmatic monitoring of voltage and fault conditions.
