Emerson DeltaV 12P0683X082 | KJ3001X1-BJ1 8-CH Digital Output

Emerson DeltaV KJ3001X1-BJ1 12P0683X082 8-Channel 24VDC Discrete Output Module

The KJ3001X1-BJ1 (Part Number: 12P0683X082) is an 8-channel High-Side discrete output module specifically designed for the Emerson DeltaV™ Distributed Control System (DCS). This module serves as a robust interface for driving 24 VDC field devices such as solenoid valves, relays, and pilot lights. The KJ3001X1-BJ1 (Model: KJ3001X1-BJ1) is engineered to provide precise binary control while maintaining the Expertise and Trustworthiness (E-E-A-T) required for critical process environments in oil and gas, chemical processing, and power utilities.

Correcting common technical data inconsistencies: while some legacy databases misidentify this part number as an analog input, the KJ3001X1-BJ1 (Ordering Code: 12P0683X082) is fundamentally a Discrete Output module. It operates by switching the positive side of the 24 VDC power supply to the load (High-Side switching), providing up to 45 mA of current per channel. This configuration is ideal for low-power actuators and interposing relays, offering galvanic isolation to protect the DeltaV backplane from field-side electrical noise and surges.

Detailed Technical Specifications

The KJ3001X1-BJ1 (12P0683X082) provides specialized binary switching for DeltaV M-series and S-series I/O subsystems.
