Honeywell MU-TAIH13 High Level Analog Input FTA (51309138-125)

Description

The Honeywell MU-TAIH13 (part number 51309138-125) is a High Level Analog Input Field Termination Assembly (FTA) designed for integration with Honeywell TPS and Experion PKS distributed control systems. This module serves as a critical interface between field instrumentation and the control system, facilitating the conversion of standard industrial analog signals into digital values for process monitoring and control.

Features

• 16 independent analog input channels supporting 4-20 mA and 0-10 V signals.
• High-resolution signal conversion with accuracy better than 0.1 percent of full scale.
• Supports redundant I/O configurations for high-availability applications, allowing seamless failover.
• Integrated signal conditioning, filtering, and channel-to-channel isolation to mitigate noise and cross-channel interference.
• Equipped with Type C compression terminals for secure, vibration-resistant field wiring.

Applications

The MU-TAIH13 is engineered for mission-critical industrial environments, including oil and gas refining, power generation, and chemical processing. It is specifically designed to reduce marshalling complexity by providing direct field wiring termination for high-density analog signal acquisition.

Technical Specifications

Installation Guidelines

• Ensure the control system is powered down before installing or removing the FTA from the cabinet.
• Use shielded twisted-pair cabling for all analog inputs to minimize EMI/RFI interference.
• Ensure proper grounding of the FTA chassis to the cabinet ground bus to maintain signal integrity.
• Verify that the compression terminals are tightened to the specified torque to prevent loose connections in high-vibration environments.
• Maintain adequate clearance around the module to ensure proper airflow and cooling within the cabinet.

FAQ

Q: Is this FTA compatible with redundant I/O setups?
A: Yes, the MU-TAIH13 is designed to support redundant I/O configurations, allowing for primary and secondary FTA operation to ensure continuous signal availability.

Q: What type of field wiring does this module accept?
A: This module utilizes Type C compression terminals, which are designed for secure, direct connection of field instrumentation wiring.
